Unity 3d 2D Eye Focus and head look By XenoAisam
Hello guys! long time no see. This time I provide some useful tools that I made myself using unity scripting and it’s for Unity-er guys like me.
It’s useful stuff for the people who make anime model and use it in unity3d. It’s free.
Sorry, no new 3d model so far for now :P
2D Eyes Focus
2D eyes focus is suitable for the model which is using fully textured on eyes area. A bit of step to do start up but its less bug so far.
- Unity 3D
- 3D model which only use a texture for each eyes. Example: (Eye texture)
+Open your ready model and Export using FBX. :
+Import the model into Unity. Make sure the size in Unity is proper scale 1 , 1 , 1
+Import the custom package of “2D Eyes Focus’
+Add Xeno Eye Iris Focus Component on 3D model inspector
+Set ‘Head Model’ or any model which have Eyes Material on it
+For the “Eye Level” you need to create child GameObject on your model.
+Make sure the axis of Z (Blue) is aligned with your model facing.
+Now you can rename your ‘GameObject’ with ‘EyeLevel. And now make the head bone as its parent
+Now set the transform position of ‘Eye Level’ to all 0, 0, 0.
Probably you want to set your rotation to 80, 270, 0. But make sure your ‘Eye Level’ z-axis is facing same direction with your model face.
+Now you can drag the ‘Eye level’ into the empty slot of Eye level in 2d eye focus inspector
+’Target’ Empty slot is the target for the iris to focus/tracking/follow around. It’s up to you what kind of target you want to use.
If you want to use script and change the target in real-time, use this method to call:
var NewTarget : Transform;
var EyeFocusScript : XenoEyeIrisFocus;
EyeFocusScript.Target = NewTarget;
+Eye Setting drop down to setting the eyes. It’s all explanatory in the inspector
Have a nice trying :)
This is simple head look script that orientate the head to face the target position.
Not as powerful as the one in Unity example demo head look, but this one is easy to modify.
It’s also self explanatory and you can try ahead yourself :)
